| 产品名称：H71对夹升降式止回阀 |
 |
一、产品对夹升降式止回阀的详细资料：
产品型号：H71
产品名称：对夹升降式止回阀
产品特点：
二、流体力学性能：H71对夹升降式止回阀的体积流量与压力降关系：
水的当量体积流量Vw与实际流体的 体积流量v按下式换算：
式中：Vw一水的当量体积流量．l／s;
P一流体密度，kg／m3v一实际流体的体积流量，I／s;
一实际流体的体积流量，I／s。
三、流体力学性能：H71对夹双瓣旋启式止回阀的流体阻力系数、流量系数及开启压力：
|
公称通径
|
阀门全开启时的流体阻力系数
|
常温下阀门全开启时的水讲E量系数
|
流体的流向
|
|
DN
|
NPS
|
Kv(m3=／h)
|
CV(U.S)
|
CV(U.K)
|
↑
|
↓
|
→
|
|
开启压力近似值KPa
|
|
15
|
1/2
|
6.4
|
2.6
|
3.0
|
2.5
|
3
|
2
|
2.5
|
|
20
|
3/4
|
5.1
|
6.4
|
7.5
|
6.3
|
3
|
2
|
2.5
|
|
25
|
4
|
4.1
|
12.6
|
14.8
|
12.3
|
3
|
2
|
2.5
|
|
32
|
11/4
|
4.1
|
19.7
|
23.1
|
19.3
|
3
|
2
|
2.5
|
|
40
|
11/2
|
3.8
|
29.5
|
63.9
|
28.9
|
3
|
2
|
2.5
|
|
50
|
2
|
3.5
|
54.6
|
99.9
|
63.5
|
3
|
2
|
2.5
|
|
65
|
21/2
|
3.5
|
85.4
|
150
|
83.7
|
3
|
2
|
2.5
|
|
80
|
3
|
3.2
|
128
|
286
|
125
|
3
|
2
|
2.5
|
|
100
|
4
|
2.8
|
244
|
286
|
249
|
3
|
2
|
2.5
|
|
125
|
5
|
2.9
|
375
|
439
|
368
|
3
|
1
|
2.2
|
|
150
|
6
|
3.1
|
522
|
611
|
512
|
3
|
1
|
2.2
|
|
200
|
8
|
3.2
|
915
|
1070
|
897
|
3
|
1
|
2.2
|
四、对夹升降式止回阀的型号、材料及主要参数：
|
配管法兰
|
公称压力
|
常规产品型号
|
|
JB/T74-90
GB9112-9124、HG20592-20614
|
PN1.0MPa
|
H71H-10C
|
H71W10P
|
H71W10P8
|
H71W10P3
|
H71W10R
|
H71W10R8
|
H71W10R3
|
|
PN1.6MPa
|
H71H-16C
|
H71H-16P
|
H71H-16P8
|
H71H-16P3
|
H71H-16R
|
H71H-16R8
|
H71H-16R3
|
|
PN2.5MPa
|
H71H-25
|
H71H-25P
|
H71H-25P8
|
H71H-25P3
|
H71H-25R
|
H71H-25R8
|
H71H-25R3
|
|
PN4.0MPa
|
H71H-40
|
H71H-40P
|
H71H-40P8
|
H71H-40P3
|
H71H-40R
|
H71H-40R8
|
H71H-40R3
|
|
PN6.3MPa
|
H71H-63
|
H71H-63P
|
H71H-63P8
|
H71H-63P3
|
H71H-63R
|
H71H-63R8
|
H71H-63R3
|
|
PN10.0MPa
|
H71H-100
|
H71H-100P
|
H71H-100P8
|
H71H-100P3
|
H71H-100R
|
H71H-100R8
|
H71H-100R3
|
|
PN16.0MPa
|
H71H-160
|
H71H-160P
|
H71H-160P8
|
H71H-160P3
|
H71H-160R
|
H71H-160R8
|
H71H-160R3
|
|
CB/T9112-9124、HG20615-20635、SH3406
|
PN2.0MPa
|
H71H-20C
|
-
|
H71H-20P8
|
H71H-20P3
|
-
|
H71H-20R8
|
H71H-20R3
|
|
PN5.0MPa
|
H71H-50
|
-
|
H71H-50P8
|
H71H-50P3
|
-
|
H71H-50R8
|
H71H-50R3
|
|
PN11.0MPa
|
H71H-110
|
-
|
H71H-110P8
|
H71H-110P3
|
-
|
H71H-110R8
|
H71H-110R3
|
|
PN15.0MPa
|
H71H-150
|
-
|
H71H-150P8
|
H71H-150P3
|
-
|
H71H-150R8
|
H71H-150R3
|
|
ANSIB16.5
|
Class150
|
H71H-A1C
|
-
|
H71H-A1CP8
|
H71H-A1P3
|
-
|
H71H-A1R8
|
H71H-A1R3
|
|
Class300
|
H71H-A3
|
-
|
H71H-A3P8
|
H71H-A3P3
|
-
|
H71H-A3R8
|
H71H-A3R3
|
|
Class600
|
H71H-A6
|
-
|
H71H-A6P8
|
H71H-A6P3
|
-
|
H71H-A6R8
|
H71H-A6R3
|
|
Class900
|
H71H-A9
|
-
|
H71H-A9P8
|
H71H-A9P3
|
-
|
H71H-A9R8
|
H71H-A9R3
|
|
主要
零件
材料
|
阀体
|
WCB(A105)
|
ZG1Cr18Ni9Ti
|
CF8(304)
|
CF3(304L)
|
ZG1Cr18Ni12Mo2Ti
|
CF8M(316)
|
CF3M(316L)
|
|
阀瓣
|
2Cr13
|
1Cr18Ni9Ti
|
0Cr18Ni9
|
00Cr19Ni10
|
1Cr18Ni12TMo2i
|
00Cr17Ni12Mo2
|
00Cr17Ni14Mo2
|
|
压圈
|
2Cr13
|
1Cr18Ni9Ti
|
0Cr18Ni9
|
00Cr19Ni10
|
1Cr18Ni12TMo2i
|
00Cr17Ni12Mo2
|
00Cr17Ni14Mo2
|
|
弹簧
|
0Cr18Ni9
|
0Cr18Ni9
|
0Cr18Ni9
|
00Cr19Ni10
|
1Cr18Ni12TMo2i
|
00Cr17Ni12Mo2
|
00Cr17Ni14Mo2
|
|
适用工况
|
适月介质
|
水、蒸汽、
油品等
|
硝酸等腐蚀性介质
|
强氧化性介质
|
醋酸等腐蚀性介质
|
屎素等腐
蚀性介质
|
|
适用温度（℃）
|
-29～425
|
-196～540
|
-196～425
|
-196～540
|
-196～455
|
|
注：本表为常规对夹式止回阀的型号编制、主要零件材料及适用工况，其他要求及其型号编制参见对夹式止回阀型号编制方法。
|
